This Professional 7″ Split Screen/ Quad Monitor features a high resolution super bright (500 cd/m2) TFT LCD panel.
This monitor can connect with up to 4 cameras and can display cameras in pairs, as a vertically split screen, individually or in quad image mode, and also features a built in SD Card slot for Recording.
KEY FEATURES
- 7.0 inch Colour Digital TFT Monitor
- SD Card Recording
- Trigger wires for auto switching of individual camera, and multiple camera display
- Selectable Reversing Grid
- Unique trigger controlled audio function to work specifically with VRUD cameras
- All materials and PCB production conform to Rohs standard
TECHNICAL DETAILS
| Display Size | 7.0″ (16:9) TFT Panel |
| Video System | 1080P/ 720P/ CVBS – 25 FPS |
| Resolution | 1024 x3(RGB) x 600 |
| Brightness | 500 cd/m² |
| Contrast | 500:1 |
| Viewing Angle | U: 50°/ D: 70°, R/L: 70° |
| Aspect Ratio | 16:9 |
| Power Consumption | Approx 14W |
| Power Input | 9V-36V |
| Video Input | 4 CH |
| Audio Input | 4 CH |
| Size | 179mm x 123mm x 29mm |
| Weight | 0.5 KG |
| Operating Temperature | -20~+70℃ |
| Storage Temperature | -30~+80℃ |
